Quiz Maker is an Android application created in Java programming language using Eclipse IDE. The application has an implementation of a local SQLite database and it allows users to create their own quiz fast and easy. Quiz Maker supports text, image and audio type content. Data can be backed up to various file formats including JSON, XML, PDF and TXT. It is also possible to back up a whole database with a single click. HTML/JavaScript version of the quiz can be easily generated for selected category.
Application intro displays title, logo, website link and buttons. The logo symbolizes letter Q which stands for quiz and brain that signifies knowledge and intelligence. User can proceed to the main menu activity by pressing on “Enter” button or leave application by pressing on “Exit” button.
Iconset
The application iconset is designed in Inkscape v0.91 and it consists of 15 icons. The icons are used for menus and other features. They are designed to be in three colors: red, blue and white.
Fill color: RGBA(ffffffff)
Stroke color: RGBA(4682b4ff)
Icon color: RGBA(ff0000ff)
Main Menu
The main menu shows a list view with 10 items that have icon and description:
1. Start Quiz – starting the quiz with selected category,
2. Quiz Editor – editing questions and answers,
3. HiScore – viewing player results,
4. Players – managing players,
5. Import – importing files,
6. Export – exporting files,
7. Backup & Restore – securing the database,
8. Database Info – displaying database usage,
9. About Program – displaying info about application,
10. Quit – exiting the application.
Quiz
The quiz activity has text views for question title, checkboxes for answers and buttons for answering or skipping question. Sound that indicates correct or wrong answer will be played after answering the question. If user does not know the answer to the question, it can be skipped. Quiz will quit by pressing the back button after confirming that action in the alert dialog.
Result
After answering all questions or quiting a quiz, result activity will appear. It will display information about total number of correct and wrong answers and percentage on a chart diagram. The chart diagram image can be saved to file by clicking on „Save Chart“ button. Clicking on „Next“ button will start activity for saving score.
Save Score
User can choose to save the current score or not. Player must be created before the score can be saved. If the player is already added in the database, user can click on „Existing Player“ button, otherwise user can click on „New Player“ button to create a new player.
Quiz Editor
The editor displays buttons for categories and questions. In order to add questions with answers, user must create a category first.
Categories
Categories can be easily searched in the text field. Every category list item contains buttons for editing and deleting a category. The number of total questions for category will appear on each list item, also. Button for adding a new category is located at the bottom of the activity. It is mandatory to create a category before questions can be inserted into the database.
Category Editor
Parameters for quiz category are name, password, confirm password and options for password prompt on start, shuffle questions and shuffle answers. Password disables editing or deleting a category by unauthorized user and password protected quizzes cannot be exported to file before entering a correct password.
Question Editor
Question and answer contents are feasible for textual, image and audio types. Each question may have unlimited number of answers. The questions can have more than one correct answer. Play and stop button will be shown for audio files and image view will be displayed for image content type. It is very simple to add or remove answers in the list view.
HiScore
HiScore list items contain player names with place and number of correct and wrong answers. The list is ordered in SQL code by multiple data table columns. Score data can be searched in the text field on the top. There is a button at the bottom for clearing all hiscore data. By pressing on it an alert dialog will ask user to confirm the action.
Score
Number with total of correct and wrong answers is visible on score activity. The list items display question text and they show information if the question was answered correct or wrong. Bitmap icon is used to indicate correct or wrong answer, too.
Players
The main purpose of player data is to identify user score in the hiscore rank list. List items show player name with registration date under. Player data can be edited only if correct password is provided. Deleting a player will result in deleting hiscore data for that player.
Player Editor
Player parameters are name, password and confirm password. The password is required for preventing unauthorized user from using a name of another user.
Import
Quizzes are available for import from JSON and XML files. Information message with total number of imported categories will be shown after a successful file import.
Export
File export manager allows exporting to HTML/JavaScript, JSON, PDF, TXT and XML file formats. All exported files are saved to Quiz Maker directory.
Backup and Restore
SQLite database can be backed up, restored and deleted very easy. The backup files are saved to “Quiz Maker/Backup” directory.
Database Info
Database info displays database usage for all tables:
1. Categories,
2. Questions,
3. Question types,
4. Answers,
5. Answer types,
6. Score items,
7. HiScore items,
8. Players,
9. Files,
10. File types.
About Program
About program activity shows program information for application name, version, programmer info and contact details and credits.
Conclusion
Quiz Maker is an easy to use Android application for making creative trivia games with textual, image and audio content. Users are enabled to create multiple quiz categories that can be password protected or not and set with options such as shuffle questions and answers. Data is available for transporting between Android devices in various file formats but this application needs a unique file format in order to make data much more transportable. It can be realized with Java serialization and that has yet to be researched and designed. Printable quiz like TXT and PDF document format content might be applied for school tests and that content can be used for a more interactive education. Students can be additionally prepared for exams and achieve increased knowledge.
Project Specifications
Name: Quiz Maker
Type: Android Application
Language: English
Programmer: Nihad Liu Karajko
E-Mail: nihadliu@gmail.com
Version: 1.0.0.6
Starting time: 12.02.2018
Ending time: 24.02.2018
Programming language: Java
Software tools: Eclipse IDE
Database: SQLite
Libraries: iTextG, JSON Simple, MPAndroidChart
Code lines: 7400
Packages: 5
Classes: 52
Database tables: 10
Project size: 6.5 MB
APK file size: 2.18 MB
